Operating elements for driving
3.2 Brief description of the operating elements
3 - 58 3 302 819 en Operating manual
GMK3060
13.12.2018
H
The cameras must not be removed or misadjusted. If a camera is mounted on the
storage box then the storage box must not be removed.
H
There may be no spare wheel installed on the rear of carrier.
Switch on
• Switch on the ignition – the monitor shows the area around the truck crane.
Switch off
• Switch off the ignition – the monitor switches off.
3.2.12 Final drive
à Longitudinal and transverse differential locks, p. 5 - 56
1 Transverse differential locks display
2 Longitudinal differential lock display
The following applies to both displays:
– Green: Locks off
– Red: Locks on
