Rigging work
12.6 Rigging/unrigging the counterweight
Operating manual 3 302 819 en 12 - 55
GMK3060
13.12.2018
12.6.4 Slinging points on the counterweight sections
•
Only use lifting gear of sufficient load bearing capacity.
Weights;
à Counterweight sections, p. 1 - 11.
• Attach the counterweight sections at the
slinging points (1).
G
Risk of accident if used improperly!
Attach the lifting gear to various counterweight section only at the appropriate
slinging points. Ensure the lifting gear has sufficient load bearing capacity.
Only lift the sections one by one, since the slinging points are not designed for
lifting stacked sections.
