Driving mode
5.3 Driving and parking the truck crane
5 - 54 3 302 819 en Operating manual
GMK3060
13.12.2018
5.3.9 Fold-up berth
The berth must always be folded up and secured for driving.
Folding down
• Tilt the backrests of the seats forwards;
à p. 5 - 12.
• Turn the locking bar (3) and fold the berth (2)
down.
• Fasten both belts in the sockets (1).
Folding up
• Turn the locking bar (3) to position Locked.
• Undo the belts from the retainers (1) and place
them on the berth.
• Fold up the berth (2) until you can hear the
locking bar (3) latch into place behind the
holder (4).
• Put up the back rests of the seats; à p. 5 - 12.
G
Risk of accidents due to the berth folding down!
Check that the locking bar has engaged and put up the back rest of the seats
before driving. This prevents the berth folding down when braking, resulting in
uncontrolled manoeuvres due to fright.
