Driving mode
5.1 Before driving
5 - 12 3 302 819 en Operating manual
GMK3060
13.12.2018
5.1.3 Adjusting the seat and the steering column
Adjusting the
driver's seat
Version 1
The seat height and lumbar area support are adjusted pneumatically. You can
only make these adjustments when:
– The switch (1) on the driver's seat is switched off (not pressed in)
– sufficient air pressure is available in the secondary consumer circuit. You may
have to build up the supply pressure;
à p. 5 - 9.
• Sit on the driver's seat; the seat will rise to the last position set.
You can make adjustments to suit your body size and shape.
– Settings for body size
1 Seat – longitudinal adjustment
2 Horizontal suspension on/off
3 Seat – inclination
4 Seat cushion – longitudinal adjustment
5 Adjust suspension stiffness to body weight
6 Seat – height
7 Back rest – angle
8 Shoulder support
