Operating elements for driving
3.2 Brief description of the operating elements
3 - 76 3 302 819 en Operating manual
GMK3060
13.12.2018
3.2.21 Windows and doors
Window winder
Button assignment
Movement stops after the button is released and
when an end position is reached.
Doors The same key is used for the driver's and passenger's door.
Locking
• To close the door
• Turn the key towards B, or
• Push down the knob (2)
Unlocking
• Turn the key towards A, or
• Push up the knob (2)
Opening
• Pull the handle (1) or
• Pull the handle (3)
G
Risk of crushing when closing the windows!
If the window winders encounter resistance, they do not stop but keep on moving
at reduced power.
A Window winder, driver's door
B Window winder, passenger door
1 To open the window
2 To close the window
