Driving with a rigged truck crane
13.5 Driving from the crane cab
Operating manual 3 302 819 en 13 - 25
GMK3060
13.12.2018
13.5.5 While driving
DM and RM trans-
mission mode
The speed is limited to approx. 8 km/h (5 mph) (only in 1st or 2nd gear).
With a load lifted, drive at the lowest possible speed, at the most 1.5 km/h
(1 mph). The speed is not automatically limited to this value.
• Use the greatest possible turning radius when you are driving around corners!
• Do not steer the truck crane when it is stationary.
Never level the truck crane with the level adjustment system if the ground is
uneven. You can level the truck crane using the outrigger or the axle raising;
à Levelling the free-standing truck crane, p. 12 - 47.
Transmission
mode D
The speed is limited to a maximum of approx. 20 km/h (12 mph) (maximum of
5th gear).
Use this transmission mode only when:
– The main boom is completely retracted
– The main boom is resting in the boom rest
– The outrigger beams/cylinders are fully retracted
Warning
messages
If a symbol is shown in area (1);
à Warning messages on the CCS display, p. 14 - 3,
à Error messages on the CCS display, p. 14 - 8.
G
Risk of accidents when driving with a lifted load!
The maximum permissible speed for driving with a lifted load is 1.5 km/h (1 mph).
S
Risk of damage to the steering linkage!
The steering linkage can be damaged if the steering wheel is moved while the
vehicle is stationary.
G
Danger of overturning by switching on the suspension!
The suspension must be deactivated (locked) while the rigged truck crane is on
wheels.
When switching on the suspension, the suspension cylinders would suddenly be
pressed together and damaged, and the truck crane could overturn.
