Malfunctions in driving mode
8.6 Tilting/lowering the driver's cab
8 - 40 3 302 819 en Operating manual
GMK3060
13.12.2018
8.6.2 Tilting and lowering the driver's cab
Operating the
hand pump
The driver's cab is tilted and lowered using a hand pump. The lever for the hand
pump is below the seats or in the tool box.
You need the socket wrench provided (3) (wrench
width 30 mm).
• Place the socket wrench on the hand pump (1).
• To tilt the driver's cab, turn the lever (2)
upwards, to the A position.
• To lower the driver's cab, turn the lever (2)
downwards, to the B position.
Before tilting the driver's cab, note the prerequisites specified at the beginning of
the section;
à Prerequisites and information on tilting, p. 8 - 39.
