Driving with a rigged truck crane
13.2 Permissible rigging modes and axle loads
13 - 2 3 302 819 en Operating manual
GMK3060
13.12.2018
13.2 Permissible rigging modes and axle loads
H
In the Free on wheels operating position, slewing is only enabled when a maximum
counterweight combination of 7.6 t (16,700 lbs) is rigged. If you wish to move the
rigged truck crane with a rigged counterweight combination of 8.6 t (18,900 lbs),
then you must first adequately support the truck crane and slew the superstruc-
ture into the 0° to the rear operating position.
• Bring the truck crane into a permissible Free on wheels operating position in
accordance with the Lifting capacity table;
à CHECKLIST: Rigging, p. 12 - 1.
A maximum counterweight combination of 8.6 t (18,900 lbs) may be rigged.
• Enter and confirm the current rigging mode at the RCL for the Free on wheels
operating position.
• For reasons of safety, extend the outrigger beams in accordance with the avail-
able space. The outrigger pads must not touch the ground whilst the crane is
being driven.
• You can drive without a load and, under certain circumstances, even with a
lifted load. Observe the information in the corresponding section.
13.2.1 To drive without a load
• Slew the superstructure to the 0° to the rear position – if slewing is not permitted
in the current Free on wheels operating position then you must support the truck
crane on outriggers before slewing.
• Lock the turntable.
• Switch off the slewing gear.
• Bring the main boom to an inclination permitted within the working range.
• Tie down the hook block so that it cannot swing around.
