Rigging work
12.7 Rigging work on the main boom
Operating manual 3 302 819 en 12 - 101
GMK3060
13.12.2018
12.7.7 Anemometer and air traffic control light
Installing The anemometer and the air traffic control light – if provided – are located on the
same rod.
• If necessary, remove the rod from the storage
compartment (1).
Depending on the additional equipment, the truck
crane can be equipped with a switchable air traffic
control light.
This air traffic control light (1) has Flashing light
and Constant light lighting modes.
• Select the desired lighting mode using the
switch (2).
s
S
Risk of damage during on-road driving
Always remove the anemometer and air traffic control light before on-road
driving.
This prevents the specified overall height from being exceeded at on-road level,
and the anemometer from being damaged due to unfavourable air currents.
