Crane operation
11.6 Settings and displays for crane operation
11 - 134 3 302 819 en Operating manual
GMK3060
13.12.2018
11.6.7 Using the slewable spotlights
With the relevant equipment, the slewable spotlights (1) are located on the main
boom. They are controlled from the crane cab.
Switching on
• Push the switch (1) in at the bottom – the lamp (2) lights up.
Switching off
• Push the switch (1) in at the top – the lamp (2) goes out.
Swing upwards
• Press the button (1) in at the top.
Turn downwards
• Press the button (1) in at the bottom.
The direction of the spotlights will be adjusted until you let go of the button or they
reach their end position.
G
Risk of accidents due to dazzling during on-road driving!
When driving on the road, always direct the spotlight in such a way that the
reflector points downwards. In this way, you can prevent yourself and other
drivers being dazzled and causing accidents.
