Crane operation
11.4 Operation of the rated capacity limiter
11 - 36 3 302 819 en Operating manual
GMK3060
13.12.2018
11.4.2 Entering the rigging mode
Notes on Input You can enter the rigging mode for various different purposes.
– Entry for crane operation
You enter the current rigging mode, select a telescope status according to the
lifting capacity table and confirm the rigging mode to enable the crane func-
tions.
– Entry for operations planning
You enter a possible rigging mode to check the lifting capacities, slewing
ranges and telescopings that are enabled with this rigging mode.
H
You can only change the rigging mode when all crane movements have stopped
– control lever in the initial position.
• If necessary, open the Enter rigging mode/telescope status menu (1) on the CCS
display.
The RCL display shows the Lifting capacity table
menu.
The CCS shows the Enter rigging mode/telescope
status for the last rigging mode entered.
Te rigging mode is entered at the CCS display –
after each change, the RCL display shows the
corresponding lifting capacity table (2) and the
enabled slewing range (1).
The input options and the displays are based on
the confirmed slewing range type.
First enter the slewing range type;
à p. 11 - 37.
