Crane operation
11.6 Settings and displays for crane operation
Operating manual 3 302 819 en 11 - 131
GMK3060
13.12.2018
11.6.4 Limiting the power unit speeds
You can enter what percentage of the maximum speed should be enabled for
each power unit.
• Open the Power unit speeds menu (1).
The values below the symbols (1) to (6) indicate
the currently set power unit speeds.
The values for the slewing gear (1) and derricking
gear (3) only apply if they are lower than the auto-
matically limited values. The automatically limited
values are not displayed.
The symbol (5) is only active when the auxiliary
hoist is connected.
With the preselection symbol for:
Symbol (9) resets all values without prior
selection.
Changing values
• Select and confirm the symbol for the relevant
power unit – symbol red.
• Change the value using switch (2) or the
buttons (3).
To cancel the input – press button (1) once.
• Confirm the changed values – press switch (2)
or button (4) once. The changed values for the
power unit are applied.
7 Operation with the lattice extension
8 Operation without the lattice extension
