Operating elements for crane operation
9.2 Brief description of the operating elements
9 - 96 3 302 819 en Operating manual
GMK3060
13.12.2018
Exiting the menu/input mode
Press button (1) or (2) to exit the menu or input mode.
Overview menu groups
Switch off RCL buzzer
In some cases not active until after 5 seconds
Jog dial display
Sensor – no function
à Display – setting the brightness, p. 4 - 11.
– Press the button once: – The opened menu closes – the menu from the
next higher level is opened
– Input mode is deactivated
1Press: – After the first press
Menu groups overview display
– After a subsequent press
Next/previous group overview
– Press once: Buzzer is switched off
1 Jog dial OK
2 Jog dial disabled
Communication fault or error (error display)
