MAX32660 User Guide

Maxim Integrated Page 125 of 195

Timer Control Register

TMRn_CN

[0x0010]

Bits

Name

Access

Reset

Description

2:0

tmode

R/W

Timer Mode Select



tmode

Selected Timer Mode

000b

One-Shot

001b

Continuous

010b

Counter

011b

PWM

100b

Capture

101b

Compare

110b

Gated

111b

Capture/Compare
