MAX32660 User Guide

Maxim Integrated Page 158 of 195

C Slave Address Register

I2Cn_SLADDR

[0x0044]

Bits

Name

Access

Reset

Description

9:0

sla

R/W

Slave Mode Slave Address

When I

C peripheral is operating in Slave Mode, I2Cn_CTRL0.mst = 0, this field

must be set as the desired slave address for the peripheral.

Table 12-22: I

C DMA Register

I2Cn_DMA

[0x0048]

Bits

Name

Access

Reset

Description

31:2

R/W

Reserved for Future Use

Do not modify this field.

rxen

R/W

RX DMA Channel Enable

0: Disable RX DMA channel

1: Enable RX DMA channel

txen

R/W

TX DMA Channel Enable

0: Disable TX DMA channel

1: Enable TX DMA channel
