MAX32660 User Guide
Maxim Integrated Page 52 of 195
below. For the 96MHz Relaxation Oscillator as the system clock, the FLC_CLKDIV.clkdiv field should be set to 96 (0x60). If
another clock source is set as the system clock, this field must be adjusted to meet the target 1MHz for f
FLC_CLK
.
Equation 5-1: Flash Controller Clock Frequency
5.3.2 Lock Protection
The Flash Controller provides a locking mechanism to prevent accidental writes and erases. Each write or erase requires the
FLC_CTRL.unlock field be set to 0x2 prior to starting the operation. Writing any other value to the FLC_CTRL.unlock field
results in the flash remaining locked.
Note: If a write, page erase or mass erase operation is started and the unlock code was not set to 0x2, the Flash Controller
hardware sets the access fail flag, FLC_INTR.access_fail, to indicate an access violation occurred.
5.3.3 Flash Write Width
The Flash Controller supports write widths of either 32-bits or 128-bits. Selection of the flash write width is controlled with
the FLC_CTRL.width field and defaults to 128-bit width on all forms of reset. Setting FLC_CTRL.width to 1 selects 32-bit write
widths.
In 128-bit width mode, the target address bits FLC_ADDR[3:0] are ignored resulting in 128-bit alignment. In 32-bit width
mode, the target address bits FLC_ADDR[1:0] are ignored for 32-bit address alignment. If the desired target address is not
128-bit aligned (FLC_ADDR[3:2] 0), 32-bit width mode is required.
Table 5-2: Valid Addresses for 32-bit and 128-bit Internal Flash Writes
