MAX32660 User Guide
Maxim Integrated Page 68 of 195
GPIO Slew Rate Select Register
GPIO0_SR_SEL
[0x00AC]
Bits
Name
Access
Reset
Description
13:10
-
R/W
0
GPIO Slew Rate Mode
Selects between fast and slow slew rate for the respective I/O pin. Setting a bit to 1
enables slow slew rate for the respective I/O pin.
0: Fast slew rate selected.
1: Slow slew rate selected.
Note: Refer to the MAX32660 datasheet for detailed electrical characteristics of the
fast and slow slew rates.
9:8
-
R/W
0
Reserved for Future Use
Do not modify this field.
7:4
-
R/W
0
GPIO Slew Rate Mode
Selects between fast and slow slew rate for the respective I/O pin. Setting a bit to 1
enables slow slew rate for the respective I/O pin.
0: Fast slew rate selected.
1: Slow slew rate selected.
Note: Refer to the MAX32660 datasheet for detailed electrical characteristics of the
fast and slow slew rates.
3:2
-
R/W
0
Reserved for Future Use
Do not modify this field.
1:0
-
R/W
0
GPIO Slew Rate Mode
Selects between fast and slow slew rate for the respective I/O pin. Setting a bit to 1
enables slow slew rate for the respective I/O pin.
0: Fast slew rate selected.
1: Slow slew rate selected.
Note: Refer to the MAX32660 datasheet for detailed electrical characteristics of the
fast and slow slew rates.
Table 6-23: GPIO Drive Strength 0 Select Register
GPIO Drive Strength 0 Select Register
GPIO0_DS0_SEL
[0x00B0]
Bits
Name
Access
Reset
Description
31:14
-
R/W
0
Reserved for Future Use
Do not modify this field.
13:10
-
R/W
0
GPIO Drive Strength 0 Select
The output drive strength supports four modes. The mode selection is set using the
combination of the GPIO0_DS1_SEL and GPIO0_DS0_SEL bits for the associated GPIO
pin. Refer to the GPIO Drive Strength section, above, for the selection options on these
I/O pins.
Refer to the symbols V
OL_GPIO
and V
OH_GPIO
in the MAX32660 Data Sheet Electrical
Characteristics table for details of the drive strengths for these I/O pins.
9:8
-
R/W
0
GPIO Drive Strength Select
Selection of high drive strength or low drive strength for the I/O pin. Pins with I
2
C as an
alternate function only support two drive strength options.
0: Low output drive strength selected.
1: High output drive strength selected.
Refer to V
OL_I2C
and V
OH_I2C
in the MAX32660 Data Sheet Electrical Characteristics table
for details of the drive strengths for these I/O pins.
