MAX32660 User Guide
Maxim Integrated Page 53 of 195
5.3.4 Flash Write
Perform the following steps to write to the internal flash memory:
1. If desired, enable Flash Controller interrupts by setting the FLC_INTR.access_fail_ie and FLC_INTR.done_ie bits.
2. Set the write field, FLC_CTRL.width, as described in Flash Write Width.
3. Set the FLC_ADDR register to a valid target address. Reference Table 5-2.
4. Set the data register or registers.
5. For 32-bit write width, set FLC_DATA0 to the data to write.
6. For 128-bit write width, set FLC_DATA3, FLC_DATA2, FLC_DATA1, and FLC_DATA0 to the data to write. FLC_DATA3
is the most significant word and FLC_DATA0 is the least significant word.
7. Set FLC_CTRL.unlock to 0x2 to unlock the internal flash.
8. Read the FLC_CTRL.busy bit until it returns 0.
9. Start the flash write, set FLC_CTRL.write to 1 and this field is automatically cleared by the Flash Controller when
the write operation is finished.
10. FLC_INTR.done is set by hardware when the write completes and if an error occurred, the FLC_INTR.access_fail flag
is set. These bits generate a flash IRQ if the interrupt enable bits are set.
5.3.5 Page Erase
Perform the following to erase a page of internal flash memory:
1. If desired, enable Flash Controller interrupts by setting the FLC_INTR.access_fail_ie and FLC_INTR.done_ie bits.
2. Set the FLC_ADDR register to a page address to erase. FLC_ADDR[12:0] are ignored by the Flash Controller to
ensure the address is page aligned. Refer to Table 5-3 for the valid page aligned addresses for the internal flash
memory.
3. Set FLC_CTRL.unlock to 0x2 to unlock the internal flash.
4. Read the FLC_CTRL.busy bit until it returns 0.
5. Set FLC_CTRL.erase_code to 0x55 for page erase.
6. Set FLC_CTRL.page_erase to 1 to start the page erase operation.
7. The FLC_CTRL.busy bit is set by the Flash Controller while the page erase is in progress and the
FLC_CTRL.page_erase and FLC_CTRL.busy are cleared by the Flash Controller when the page erase is complete.
8. FLC_INTR.done is set by hardware when the page erase completes and if an error occurred, the
FLC_INTR.access_fail flag is set. These bits generate a flash IRQ if the interrupt enable bits are set.
Table 5-3: Page Boundary Address Range for Page Erase Operations
FLC_ADDR[31:0]
Bit Number
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Page Aligned
Address
0
0
0
0
0
0
0
0
0
0
0
0
0
0
x
x
x
x
x
0
0
0
0
0
0
0
0
0
0
0
0
0
