MAX32660 User Guide
Maxim Integrated Page 130 of 195
Watchdog Timer 0 Control Register
WDT0_CTRL
0x0000 [0x00]
Bits
Name
Access
Reset
Description
7:4
rst_period
R/W
0
Reset Period
Sets the number of PCLK cycles until a system reset occurs if the watchdog timer is
not reset.
0xF:


0xE:


0xD:


0xC:


0xB:


0xA:


0x9:


0x8:


0x7:


0x6:


0x5:


0x4:


0x3:


0x2:


0x1:


0x0:


3:0
int_period
R/W
0
Interrupt Period
Sets the number of PCLK cycles until a watchdog timer interrupt is generated.
0xF:


0xE:


0xD:


0xC:


0xB:


0xA:


0x9:


0x8:


0x7:


0x6:


0x5:


0x4:


0x3:


0x2:


0x1:


0x0:


Table 11-4: Watchdog Timer Reset Register
Watchdog Timer 0 Reset Register
WDT0_RST
0x0004 [0x04]
Bits
Name
Access
Reset
Description
31:8
-
RO
0
Reserved for Future Use
Do not modify this field.
7:0
wdt_rst
R/W
0
Reset Register
Writing the watchdog counter reset sequence to this register resets the
watchdog counter. The following is the required reset sequence to reset the
watchdog and prevent a watchdog timer interrupt or watchdog system reset.
Write WDT0_RST: 0x0000 00A5
Write WDT0_RST: 0x0000 005A
