I
2
C Interrupt Enable 1 Register
I2Cn_INTEN1
[0x0014]
Bits
Name
Access
Reset
Description
0
rxofie
R/W
0
Slave Mode RX FIFO Overflow Interrupt Enable
In slave mode operation, set this field to enable the RX FIFO overflow interrupt.
0: Interrupt disabled.
1: Interrupt enabled.
Table 12-10: I
2
C FIFO Length Registers
I
2
C FIFO Length Register
I2Cn_FIFOLEN
[0x0018]
Bits
Name
Access
Reset
Description
31:16
-
R/W
0
Reserved for Future Use
Do not modify this field.
15:8
txlen
RO
8
TX FIFO Length
Returns the length of the TX FIFO.
8: 8-byte TX FIFO.
7:0
rxlen
RO
8
RX FIFO Length
Returns the length of the RX FIFO.
8: 8-byte RX FIFO.
Table 12-11: I
2
C Receive Control Registers 0
I
2
C Receive Control Register 0
I2Cn_RXCTRL0
[0x001C]
Bits
Name
Access
Reset
Description
31:12
-
R/W
0
Reserved for Future Use
Do not modify this field.
11:8
rxth
R/W
0
RX FIFO Threshold Level
Set this field to the required number of bytes to trigger a RX FIFO threshold event.
When the number of bytes in the RX FIFO is equal to or greater than this field, the
hardware sets the I2Cn_INTFL0.rxthi bit indicating an RX FIFO threshold level event.
0: 0 bytes or more in the RX FIFO causes a threshold event.
1: 1+ bytes in the RX FIFO triggers a receive threshold event (recommended
minimum value).

8: RX FIFO threshold event only occurs when the RX FIFO is full.
7
rxfsh
R/W1O
0
Flush RX FIFO
Write 1 to this field to initiate a RX FIFO flush, clearing all data in the RX FIFO. This
field is automatically cleared by hardware when the RX FIFO flush completes. Writing
0 has no effect.
0: RX FIFO flush complete or not active.
1: Flush the RX FIFO
6:1
-
R/W
0
Reserved for Future Use
Do not modify this field.
0
dnr
R/W
0
Do Not Respond
Slave mode operation only.
0: If the RX FIFO contains data and an external master requests a WRITE
transaction, respond to an address match with an ACK but NACK the subsequent
data byte(s). (No additional data is written into the RX FIFO.)
1: If the RX FIFO contains data and a master requests a WRITE transaction, do not
respond to an address match and send a NACK instead.
