MAX32660 User Guide

Maxim Integrated Page 50 of 195

Low-Power Memory Shutdown Register

PWRSEQ_LPMEMSD

[0x0040]

Bits

Name

Access

Reset

Description

sram2_off

R/W

System RAM 2 (0x2000 7FFF - 0x2000 FFFF) Shut Down

Write 1 to shut down power to System RAM 2 memory range.

0: System RAM 2 Powered On (Enabled)

1: System RAM 2 Powered Off (Disabled)

sram1_off

R/W

System RAM 1 (0x2000 3FFF - 0x2000 7FFF) Shut Down

Write 1 to shut down power to System RAM 1 memory range.

0: System RAM 1 Powered On (Enabled)

1: System RAM 1 Powered Off (Disabled)

sram0_off

R/W

System RAM 0 (0x2000 0000 – 0x2000 3FFF) Shut Down

Write 1 to shut down power to System RAM 0 memory range.

0: System RAM 0 Powered On (Enabled)

1: System RAM 0 Powered Off (Disabled)
