CHARGING SYSTEM
01–17–1
01–17
01–17 CHARGING SYSTEM
CHARGING SYSTEM OUTLINE . . . . . . . 01–17–1
Features. . . . . . . . . . . . . . . . . . . . . . . . 01–17–1
CHARGING SYSTEM
STRUCTURAL VIEW . . . . . . . . . . . . . . 01–17–1
BATTERY CONSTRUCTION . . . . . . . . . . 01–17–2
GENERATOR CONSTRUCTION . . . . . . . 01–17–2
End of Toc
CHARGING SYSTEM OUTLINE
CHU011701008S01
Features
End Of Sie
CHARGING SYSTEM STRUCTURAL VIEW
CHU011701008S02
End Of Sie
Improved reliability • A battery duct adopted
Miniaturization • A regulatorless generator with built-in power transistor adopted
BATTERY
GENERATOR
CHU0117S001
