ON-BOARD DIAGNOSTIC
05–02–3
05–02
MIL: Malfunction Indicator Lamp
DC: Drive Cycle
CCM: Comprehensive Component Monitor
End Of Sie
MEMORY FUNCTION
CHU050201026S04
• The memory function stores malfunction information detected in the malfunction detection function. Once
malfunction information is stored, the memory will not be cleared even when the ignition switch is turned off
(LOCK position) or the malfunction is repaired.
• The stored memory (malfunction information) can be cleared using the WDS or equivalent, or by disconnecting
the negative battery cable.
End Of Sie
MALFUNCTION INDICATION FUNCTION
CHU050201026S05
• The malfunction indication function illuminates the MIL or AT warning light when the malfunction detection
function determines there is a malfunction.
End Of Sie
FAIL-SAFE FUNCTION
CHU050201026S06
• In the fail-safe function, minimum vehicle drivability is obtained by changing the signals that are determined to
be malfunctions by the malfunction detection function to the preset values, and limiting TCM control.
U0073 CAN bus off OFF NO 1 CCM ×
U0100 TCM cannot receive any signals from PCM ON YES 1 CCM ×
DTC No. Condition MIL
AT warning
light
illuminated
DC
Monitor
item
Memory
function
DTC
No.
On-board diagnostic
function
Detection condition Fail-safe TCC
P0705
Transmission range (TR)
switch circuit malfunction
(short to power supply)
• Two or more range signals are input
from the TR switch for 12 s or more.
• Driving restricted to 3GR
• Stops operation of TCC
solenoid valve (OFF).
Disabled
P0706
Transmission range (TR)
switch circuit malfunction
(open circuit/short to
ground)
• No range signal is input from the TR
switch for 100 s or more.
• Driving restricted to 3GR
• Stops operation of TCC
solenoid valve (OFF).
Disabled
P0707
M range switch, up switch
or down switch circuit
malfunction (open circuit/
short to ground)
M range switch circuit malfunction
• M range switch off with up or down
switch on.
• M range switch remains on for 10 s or
more except in D range.
Up switch or down switch circuit
malfunction
• When all of the following conditions
are met:
— M range switch off.
— Except D range.
— Up or down switch remains on for
10 s or more.
M range switch circuit
malfunction
• Inhibits manual mode
Up switch or down switch
circuit malfunction
• Inhibits manual shifting
using the up switch or
down switch
Enabled
P0708
Steering shift switch circuit
malfunction (open circuit/
short to ground)
• Signal from shift control switch is 0.5
V or less, or 4.7 V or more for 10 s
or more.
• Inhibits manual shifting
using the steering shift
switch
Enabled
P0711
Transmission fluid
temperature (TFT) sensor
malfunction (stuck)
• ATF temperature remains 20 °C {68
°F} or less for 6.5 min or more.
N/A Enabled
P0712
Transmission fluid
temperature (TFT) sensor
circuit malfunction (short to
ground)
• Signal from TFT sensor is 0.1 V or
less for 150 s or more.
• Engine coolant
temperature signal is used
for shifting.
• Feedback control disabled
• Torque reduction control
disabled
• If the ECT has a
malfunction, ATF
temperature is controlled
at 80 °C {176 °F}
Enabled
