ON-BOARD DIAGNOSTIC
05–02–2
MALFUNCTION DETECTION FUNCTION
CHU050201026S03
Malfunction Detection Function
• In the malfunction detection function, the TCM detects malfunctions in the automatic transmission while driving.
• When vehicle driving conditions correspond with a preset malfunction detection condition, the TCM determines
that the automatic transmission has a malfunction and stores the corresponding DTC.
• When a malfunction is detected, stored DTCs can be retrieved using the WDS or equivalent connected to the
DLC-2.
DTC Table
×: Available
DTC No. Condition MIL
AT warning
light
illuminated
DC
Monitor
item
Memory
function
P0705
Transmission range (TR) switch circuit malfunction (short to
power supply)
ON YES 2 CCM ×
P0706
Transmission range (TR) switch circuit malfunction (open
circuit/short to ground)
ON YES 2 CCM ×
P0707
M range switch, up switch or down switch circuit malfunction
(open circuit/short to ground)
OFF YES 1 CCM ×
P0708
Steering shift switch circuit malfunction (open circuit/short to
ground)
OFF YES 1 CCM ×
P0711
Transmission fluid temperature (TFT) sensor malfunction
(stuck)
ON NO 2 CCM ×
P0712
Transmission fluid temperature (TFT) sensor circuit
malfunction (short to ground)
ON YES 1 CCM ×
P0713
Transmission fluid temperature (TFT) sensor circuit
malfunction (open circuit/short to power supply)
ON YES 1 CCM ×
P0715 Turbine sensor circuit malfunction ON YES 1 CCM ×
P0720
Vehicle speed sensor (VSS) malfunction (open circuit/short to
ground)
ON YES 1 CCM ×
P0731 Gear 1 incorrect (incorrect gear ratio detected) OFF NO 1 CCM ×
P0732 Gear 2 incorrect (incorrect gear ratio detected) OFF NO 1 CCM ×
P0733 Gear 3 incorrect (incorrect gear ratio detected) OFF NO 1 CCM ×
P0734 Gear 4 incorrect (incorrect gear ratio detected) OFF NO 1 CCM ×
P0740 TCC system malfunction ON NO 2 CCM ×
P0743
Torque converter clutch (TCC) solenoid valve circuit
malfunction (open circuit/short to ground or power supply)
ON YES 1 CCM ×
P0748
Pressure control solenoid circuit malfunction (open circuit/short
to ground or power supply)
OFF YES 1 CCM ×
P0751 Shift solenoid A malfunction (stuck off) ON NO 2 CCM ×
P0753
Shift solenoid A circuit malfunction (open circuit/short to ground
or power supply)
ON YES 1 CCM ×
P0758
Shift solenoid F circuit malfunction (open circuit/short to ground
or power supply)
ON YES 1 CCM ×
P0761 Shift solenoid B malfunction (stuck off) ON NO 2 CCM ×
P0762 Shift solenoid B malfunction (stuck on) ON NO 2 CCM ×
P0763
Shift solenoid B circuit malfunction (open circuit/short to ground
or power supply)
ON YES 1 CCM ×
P0766 Shift solenoid C malfunction (stuck off) ON NO 2 CCM ×
P0767 Shift solenoid C malfunction (stuck on) ON NO 2 CCM ×
P0768
Shift solenoid C circuit malfunction (open circuit/short to
ground or power supply)
ON YES 1 CCM ×
P0841 Oil pressure switch B circuit malfunction OFF YES 2 CCM ×
P0846 Oil pressure switch C circuit malfunction OFF YES 2 CCM ×
P0871 Oil pressure switch F circuit malfunction OFF YES 2 CCM ×
P0882 TCM B+ low ON NO 1 CCM ×
P0960 GND return circuit malfunction ON YES 1 CCM ×
P1759 2-4 brake fail-safe valve malfunction OFF YES 2 CCM ×
P1764 Low and reverse brake fail-safe valve malfunction OFF YES 2 CCM ×
