AUTOMATIC TRANSMISSION
05–13–46
COOLING SYSTEM OUTLINE
CHU051319900S02
• A water-cooling type AT oil cooler is adopted and installed in the radiator. The oil cooler cools the ATF heated in
the AT body.
End Of Sie
POWER PLANT FRAME (PPF) FUNCTION
CHU051319900S03
• The Power Plant Frame feature has been adopted for all models. For detailed information, refer to the Y16M-D
manual transmission description. (See 05–11–12 POWER PLANT FRAME (PPF) FUNCTION.)
End Of Sie
IN
OUT
OUT
IN
BHJ0513N045
