SEATS
09–13–3
09–13
POWER SEAT CONSTRUCTION/OPERATION
CHU091357101S02
• The following motors are built into the seat:
— Slide motor
— Recliner motor
— Front tilt motor
— Rear tilt motor
— Lumbar support motor
• The slide, front tilt and rear tilt switches are all operated by use of a single switch knob.
End Of Sie
(a)
(a)
(b)
(b)
(c)
(c)
(d)
(e)
(e)
(a)
(b)
(c)
(e)
(d)
(d)
FRONT TILT MOTOR
REAR TILT MOTOR
LUMBAR SUPPORT MOTOR
RECLINER MOTOR
SLIDE MOTOR
FRONT TILT SWITCH
SLIDE SWITCH
REAR TILT SWITCH
LUMBAR SUPPORT
SWITCH
RECLINER SWITCH
REAR TILT OPERATION
LUMBAR SUPPORT OPERATION
FRONT TILT OPERATION
SLIDE OPERATION
RECLINER OPERATION
CHU0913S103
