LIGHTING SYSTEMS
09–18–14
*
1 : After interior light is turned off according to this cancel condition, the light will illuminate again when either of
the following conditions are satisfied
• After all doors are closed, then any door is reopened. (After All door switches are off, any door switch is on.)
• Ignition switch is at the ON position. (IG on.)
End Of Sie
• Turn the ignition switch to the
LOCK or ACC position.
• Any door open.
(Any door switch is on.)
• Driver's door lock knob is unlocked.
(Door lock-link switch is in unlock
position.)
All doors are closed.
(All door switches
are off.)
Aprox.15
s
60 %
• Turn the ignition switch to the ON
position.
• Any door open. (Any door switch is
on.)
• Driver's door lock knob is locked.
(Door lock-link switch is in lock
position.)
• After illumination time.
*1
Conditions before operation
(Conditions which must be satisfied)
Operation
condition
Interior light
Cancel condition
(When any condition satisfied)
Illuminat
ion time
Brightne
ss
LOCK
UNLOCK
ON
OFF
ON
OFF
ON
OFF
ON
OFF
DOOR
LOCK-LINK
SWITCH
DOOR
SWITCH
KEYLESS
SWITCH
IG1
MAP LIGHT
INTERIOR LIGHT
COURTESY LIGHT
VIEW A
t
3 t3 t3
t3t3
t3 t3t2
100%
60%
t
2
t1
t1 : APPROX. 30 s
t
2 : APPROX. 15 s
t
3 : APPROX. 1 s
t
4 : APPROX. 5 min
t4
t3
t3
