11.7 Printer
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
112
￭￭￭￭￭￭￭￭
900 Touch Control
CAUTION
If the computer on which the network printer is configured does not
have the same subnet as the Touch Control, then a WINS server must
be present. The computer must be entered in this server. In order for
the communication to work, the SMB protocol version 1 (SMBv1) must
be activated. Since this function is not standard anymore in Windows
10, it has to be activated manually.
Print server
Host name of the print server or the computer on which the network
printer is configured. If you are working with Windows, then you will find
the host name as follows: In the Windows command prompt window,
enter the command ipconfig -all. The host name is listed together with
other parameters of the print server or the computer.
Do not under any circumstances enter an IP address in this input field.
Entry max. 32 characters
Default value empty
Share name
Share name of the network printer on the above-specified computer.
Please note that the Share name of a network printer often does not
match the name of the printer. The share name can be found on the
Release tab in the Properties dialog of the released network printer.
Entry max. 32 characters
Default value empty
Domain
Network domain in which the above-specified computer is located. If you
are working with Windows, then you will find the domain name as fol-
lows: In the Windows command window, enter the command ipconfig
-all. The domain is listed together with other parameters of the computer.
Leave the field empty if the computer is not located within a domain.
Entry max. 32 characters
Default value empty
User
User name of the user authorized to access the shared network printer.
Entry max. 32 characters
Default value empty
