29.13 Calculations
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
432
￭￭￭￭￭￭￭￭
900 Touch Control
Variable Description
XAP Volume/quantity of maximum measured value
XAM Maximum measured value
XAT Temperature at maximum measured value
XAD Time at maximum measured value
BP# Volume of break point BP# (# = 1 - 9)
BM# Measured value of break point BP# (# = 1 - 9)
BT# Temperature at break point BP# (# = 1 - 9)
BD# Time at break point BP# (# = 1 - 9)
RD# Mean rate in time slot # (# = 1 - 9)
RDS# Standard deviation for RD# (# = 1 - 9)
RDC# Correlation coefficient for RD# (# = 1 - 9)
RM Mean rate for whole range
RMS Standard deviation for RM
RMC Correlation coefficient for RM
Results, statistics
R# Result (# = 1 - 9)
SMN# Mean value of result R# (# = 1 - 9)
SSA# Absolute standard deviation of SMN# (# = 1 - 9)
SSR# Relative standard deviation of SMN# in % (# = 1 - 9)
SNR# Number of results from which the mean value SMN# was calculated (# = 1 - 9)
SSD Number of determinations that are carried out for the statistics calculations
SNT Statistics status (statistics activated = 1, statistics deactivated = 0)
Common variables
CV# Common variable (# = 1 - 25)
System variables
%RN Sample number, i.e. number that is increased by one at each start of a determination
%SC Start counter, see dialog More determination data / Properties
%AS Autostart status (autostart activated = 1, autostart deactivated = 0)
%AC Autostart counter, i.e. number of autostarts already carried out
%AD Autostart setpoint counter, i.e. number of autostarts to be carried out
%SS Status of the sample table (sample table activated = 1, sample table deactivated = 0)
%SL Number of the current sample table line
%SE Last sample in the sample table processed (yes = 1, no = 0)
