32.10 Diagnosis
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
526
￭￭￭￭￭￭￭￭
900 Touch Control
1
Connecting the curve simulator
NOTICE
Note that the dosing device is always located as the last device,
after the curve simulator, if there is a chain of MSB devices (e.g.
Titrando-MSB – stirrer – curve simulator – dosing device).
If the internal dosing drive on the Titrando is used, then the curve
simulator must be connected to MSB connector 2.
￭ Switch off the Touch Control.
￭ Connect the analog output of the curve simulator to the electrode
connector of the Titrando.
– Use the 6.2116.020 cable.
– Electrode connector Ind.: Simulation of an acid-base titra-
tion.
– Electrode connector Pol.: Simulation of a Karl Fischer titra-
tion.
￭ Connect the curve simulator to an MSB connector on the
Titrando.
2
Configuring the Touch Control
￭ Switch on the Touch Control.
￭ In the System / Diagnosis dialog, tap on the [822 Curve Simu-
lator] button.
The Diagnosis / 822 Curve Simulator dialog is displayed.
￭ Activate the parameter Send dosing signals to MSB2 and con-
firm with [Set].
￭ Tap on [ ].
The signals from the dosing device will now be copied to the MSB
connector 2.
3
Simulating a titration
￭ Create a titration method or load an existing one.
￭ Tap on [ ].
The titration is started. After the completion of the titration, the
results dialog is displayed.
4
Finishing the simulation mode
￭ Switch off the Touch Control.
