Start Analysis ASAP 2460 Operator’s Manual
4-6 246-42800-01 - Aug 2013
Field or Button Description (continued)
Bath temperature text field
Enabled if you have chosen to enter the bath temperature ( p
o
and
T option on the Analysis Conditions dialog). Enter (or confirm)
the temperature for the analysis bath.
Report After Analysis button Refer to Common Fields and Buttons - Unit Menu Options,
page 4-2.
Start button Begins the analysis.
Suspend button Click to suspend an analysis in progress. Select the ports
containing the analysis to suspend.
Resume button Click to resume an analysis. Select the ports containing the
analysis to resume.
Skip button Click to skip to the next step. This button is visible only when an
analysis is in progress. Select the ports containing the step to skip.
Suspend Resume Skip
Port buttons
l
Live graph settings
