the destination IP addresses cannot be reached, the message will
not
be
sent to the remaining addresses. Select the
Parallel send to all
option to
prevent this from happening.
-
Parallel send to all
: Sends the network message to all IP addresses speci-
fied in Destination Addresses at once. The message will be sent to all
specified IP addresses.
-
Send to next on error
: Sends the network message to all IP addresses
specified in Destination Addresses, until one message has been deliv-
ered successfully. Once the message has been delivered successfully to
an IP address, the camera stops sending the network message. The mes-
sage is hence only delivered to the first recipient from the list of recipients,
which successfully receives the network message.
• Transfer Protocol: Set the protocol to use for sending the network message.
-
Raw TCP/IP
: Sends the raw data in TCP/IP packets.
-
HTTP/1.0 Request
: Sends the message as an HTTP request. This also
makes it possible to use variables. For more information on variables, see
the
Using Variables
topic in the camera help and the reference manual.
• Notification Data:
-
Plain text
: Sends the text as specified in the Message field (this field
allows using variables).
-
MxPEG or JPEG clip
: Select
MxPEG clip file
to transfer an MxPEG video and
audio clip or
Clip as JPEG file(s)
from the Clip File Type list. Set the remain-
ing parameters as required (clip frame rate as well as the time before
and after the event you would like to include in the clip).
-
Image information (JPEG comment)
: Send the information from the JPEG
comment of the current live image.
-
System Messages
: Sends the messages listed in Admin Menu > System
Messages.
• Send Port: Sets the port for sending the network message (the default port
0
sets the send port automatically).
