Monarch NICE1000 User Manual

NICE1000
new
User Manual Function Code Table
- 87 -
Function
Code
Parameter Name Setting Range Default Unit
Property
F5-07 X7 function selection
13: Reserved
14: Elevator lock signal
15: Up limit signal
16: Down limit signal
17: Up slow-down signal
18: Down slow-down signal
19: Overload signal
20: Full-load signal
21: Emergency stop (safety
feedback) signal
22: Door 1 open limit signal
23: Door 2 open limit signal
24: Door 1 close limit signal
25: Door 2 close limit signal
26: Door machine 1 light
curtain signal
27: Door machine 2 light
curtain signal
28: Attendant signal
29: Direct travel ride signal
30: Direction change signal
31: Independent running
signal
31: Door 2 selection signal
33: UPS valid signal
34: Door open button
35: Door close button
36: Safety circuit
37: Door lock circuit 1
38: Door lock circuit 2
39: Half-load signal
40: Motor overheat signal
41: Door machine 1 safety
edge signal
42: Door machine 2 safety
edge signal
43: Earthquake signal
44: Back door forbidden
signal
(To be continued)
12 -
★
F5-08 X8 function selection 14 -
★
F5-09 X9 function selection 115 -
★
F5-10 X10 function selection 116 -
★
F5-11 X11 function selection 117 -
★
F5-12 X12 function selection 118 -
★
F5-13 X13 function selection 119 -
★
F5-14 X14 function selection 22 -
★
F5-15 X15 function selection 126 -
★
F5-16 X16 function selection 28 -
★
F5-17 X17 function selection 30 -
★
F5-18 X18 function selection 124 -
★
F5-19 X19 function selection 00 -
★
F5-20 X20 function selection 00 -
★
