Motion Control Engineering Motion 4000 User Manual

Appendix
A-10 Manual # 42-02-2P24
Configure C0
C1 User Switches
Spd Command Src Speed Command Source - Analog input
Multi-step
Serial
Multi-step Serial
Run Command Src Run Command Source - External TB
Serial
Serial+extern
External
TB1
Serial
Hi/Lo Gain Src High / low gain change switch source - External TB 1
Serial
Internal
Internal
Speed Reg Type Chooses speed regulator - Elev spd reg
Pi speed reg
Elev spd
reg
Motor Rotation Allows user to reverse direction of motor rota-
tion
-Forward
Reverse
Forward
Spd Ref Release Determines when speed reference release is
asserted
-Reg release
Brake picked
Reg
release
Cont Confirm Src Enables external logic input for contactor con-
firmation.
-None
External TB
None
Pre Torque Source Enables and determines the source of the pre
torque command
-None
Analog input
Serial
None
Pre Torque Latch Determines if analog pre-torque command is
latched
-Not latched
Latched
Not
latched
PT torq Latch Clck Determines source of pre torque latch control
(if used)
-External TB
Serial
External
tb
Fault Reset Src Fault reset source - External TB
Serial
Automatic
External
tb
Overspd Test Src Determines external logic source to trigger
overspeed test
-External TB
Serial
External
tb
Brake Pick Src If drive controls mechanical brake, determines
source of brake pick command
- Internal
Serial
Internal
Brake Pick Cnfrm Enables a logic input to use for brake pick con-
firmation
-None
External TB
None
Brake Hold Src If drive controls mechanical brake, determines
source of brake hold command
- Internal
Serial
Internal
Ramped Stop Sel Selects normal stop or torque ramp down stop - None
Ramp on stop
None
Ramp Down En Src Determines the source that signals the torque
ramp down stop (if used)
-External TB
Run logic
Serial
External
tb
Brk Pick Flt Ena Brake pick fault enable - Enable
Disable
Disable
Brk Hold Flt Ena Brake hold fault enable - Enable
Disable
Disable
Ext Torq Cmd Src When Speed Reg Type = External Reg, sets
the source of the torque command
-None
Serial
None
Table A.2 Magnetek AC Drive Table
#
Operator
Display
Parameter Description Unit
Setting
Range
MCE
Defaults
Field Set
