Magnetek Parameters Table
A-11
A
Motion 4000
Dir Confirm Confirms proper analog signal polarity when
enabled and a logic input is programmed to
Run Up and Run Down
-Enabled
Disabled
Disabled
S-Curve Abort Addresses how the S-Curve Speed Reference
Generator handles a reduction in the speed
command before the S-Curve Generator has
reached its target speed.
-Enabled
Disabled
Disabled
Fast Flux Reduces starting takeoff time by reducing
motor fluxing time
-Enabled
Disabled
Enabled
Main DIP Ena Enables the Mains DIP Speed (A1) parameter
that reduces speed when an undervoltage
alarm is declared
-Enabled
Disabled
Disabled
DB Protection Dynamic braking Protection fault or alarm
selection
Fault
Alarm
Fault
Encoder Fault Temporarily disables the Encoder Fault - Enabled
Disabled
Enabled
Stopping Mode Determines stopping mode when Spd Com-
mand Src = multi-step
- Immediate
Ramp to stop
Immedi-
ate
Motor Ovrld Sel Motor Overload Selection - Alarm
Flt Immediate
Fault at Stop
Alarm
Auto Stop Auto Stop Function enable - Disable
Enable
Disable
Serial Mode Serial Protocol selection - Mode 1
Mode 2
Mode 2 test
Mode 1
SER2 FLT Mode Defines reaction to a serial communication
fault while in Serial Mode 2 (Only serial mode
2)
- immediate Immedi-
ate
Run
remove
rescue
DRV Fast Disable Addresses how fast the drive responds to the
removal of Drive Enable logic input.
-Disable Disable
Enable
MLT-SPD to DLY1 Assigns multi-step speed command to recog-
nition delay timer 1
- None None
mspd1-
mspd15
MLT-SPD to DLY2 Assigns multi-step speed command to recog-
nition delay timer 1
- None None
mspd1-
mspd15
MLT-SPD to DLY3 Assigns multi-step speed command to recog-
nition delay timer 1
- None None
mspd1-
mspd15
MLT-SPD to DLY4 Assigns multi-step speed command to recog-
nition delay timer 1
- None None
mspd1-
mspd15
C2 Logic Inputs
Log In 1 TB1-1 Terminal 1 Selection - - DRIVE
ENABLE
Log In 2 TB1-2 Terminal 2 Selection - - RUN UP
Table A.2 Magnetek AC Drive Table
#
Operator
Display
Parameter Description Unit
Setting
Range
MCE
Defaults
Field Set
