F7 Settings Record
A-19
A
Motion 4000
144
Slew Filter: Smooths any harsh transitions in
the commanded speed. Reducing this value
causes a smoother transition.
145
Contract Overspeed: Setting in feet per min-
ute above contract speed at which a contract
overspeed is detected.
146
Inspection Overspeed: Setting in feet per min-
ute above inspection speed at which an
inspection overspeed is detected and an emer-
gency stop initiated.
147
Leveling Overspeed: Setting in feet per minute
above leveling speed at which a leveling over-
speed is detected and an emergency stop initi-
ated.
148
Hoist-motor Speed: Setting in drive sheave
RPM at which the car achieves contract speed.
149
Contract Speed: Contract speed of the car in
feet per minute.
150
High Speed: High speed limit for the Standard
curve. Usually the same as Contract Speed.
151 Intermediate Speed
152 Earthquake Speed
153 Auxiliary Speed
154 Backup power speed
155 Inspection Speed (Normal)
156 Inspection Speed (Reduced)
157 Correction Speed
158 Leveling Speed
159 Releveling Speed
160 Leveling Distance
161 Releveling distance
162 Proximity distance
165 Standard Start Jerk
166 Standard Roll Jerk
167 Standard Stop Jerk
168 Standard Acceleration
169 Standard Deceleration
170 Manual Start Jerk
171 Manual Roll Jerk
172 Manual Stop Jerk
173 Manual Acceleration
174 Manual Deceleration
Table A.3 F7 Parameter Log
ID# Description Setting
