Motion Control Engineering Motion 4000 User Manual

Installation
2-38 Manual # 42-02-2P24
Notch Filter Frq Notch Filter Center Frequency Hz 5 - 60 20 20
Notch Filt Depth Notch filter maximum attenuation % 0 - 100 0 0
MSPD Delay 1-4 Recognition time delay for a defined multistep
speed command
sec 0.00 - 10.0 0.00 0.00
A2 S-Curves
Accel Rate 0 Acceleration rate #0
ft/s
2
0 - 7.99 3.00 0.00
Decel Rate 0 Deceleration rate #0
ft/s
2
0 - 7.99 3.00 0.00
Accel Jerk in 0 Rate of increase of acceleration, up to ACCEL
Rate, when increasing elevator speed
ft/s
3
0 - 29.9 8.0 0.0
Accel Jerk out 0 Rate of decrease of acceleration to zero when
approaching contract elevator speed
ft/s
3
0 - 29.9 8.0 0.0
Decel Jerk in 0 Rate of increase of deceleration, up to Decel
Rate, when decreasing elevator speed
ft/s
3
0 - 29.9 8.0 0.0
Decel Jerk out 0 Rate of decrease of deceleration to zero when
slowing the elevator to leveling speed
ft/s
3
0 - 29.9 8.0 0.0
Accel Rate 1 Acceleration rate #1
ft/s
2
0 - 7.99 3.00 0.0
Decel Rate 1 Deceleration rate #1
ft/s
2
0 - 7.99 3.00 0.0
Accel Jerk in 1 Rate of increase of acceleration, up to ACCEL
Rate, when increasing elevator speed
ft/s
3
0 - 29.9 8.0 0.0
Accel Jerk out 1 Rate of decrease of acceleration to zero when
approaching contract elevator speed
ft/s
3
0 - 29.9 8.0 0.0
Decel Jerk in 1 Rate of increase of deceleration, up to Decel
Rate, when decreasing elevator speed
ft/s
3
0 - 29.9 8.0 0.0
Decel Jerk out 1 Rate of decrease of deceleration to zero when
slowing the elevator to leveling speed
ft/s
3
0 - 29.9 8.0 0.0
Accel Rate 2 Acceleration rate #2
ft/s
2
0 - 7.99 3.00 0.00
Decel Rate 2 Deceleration rate #2
ft/s
2
0 - 7.99 3.00 0.00
Accel Jerk in 2 Rate of increase of acceleration, up to ACCEL
Rate, when increasing elevator speed
ft/s
3
0 - 29.9 8.0 0.0
Accel Jerk out 2 Rate of decrease of acceleration to zero when
approaching contract elevator speed
ft/s
3
0 - 29.9 8.0 0.0
Decel Jerk in 2 Rate of increase of deceleration, up to Decel
Rate, when decreasing elevator speed
ft/s
3
0 - 29.9 8.0 0.0
Decel Jerk out 2 Rate of decrease of deceleration to zero when
slowing the elevator to leveling speed
ft/s
3
0 - 29.9 8.0 0.0
Accel Rate 3 Acceleration rate #3
ft/s
2
0 - 7.99 3.00 0.00
Decel Rate 3 Deceleration rate #3
ft/s
2
0 - 7.99 3.00 0.00
Accel Jerk in 3 Rate of increase of acceleration, up to ACCEL
Rate, when increasing elevator speed
ft/s
3
0 - 29.9 8.0 0.0
Accel Jerk out 3 Rate of decrease of acceleration to zero when
approaching contract elevator speed
ft/s
3
0 - 29.9 8.0 0.0
Decel Jerk in 3 Rate of increase of deceleration, up to Decel
Rate, when decreasing elevator speed
ft/s
3
0 - 29.9 8.0 0.0
Decel Jerk out 3 Rate of decrease of deceleration to zero when
slowing the elevator to leveling speed
ft/s
3
0 - 29.9 8.0 0.0
Table 2.5 Magnetek AC Drive Table
# Display Parameter Description Unit Range Defaults Factory
