Trainee Guide TR-L2-M2000
Level 2 Maintenance Training - M2000 Dispensing Systems 2-2-56 P/N 73-0018-00 (Revision B)
Exercise Sheet 2-7-5
Probe Removal and Replacement – HS Series
Tools and Materials Needed:
 1/16-inch hex key
 New Height Sensor probe
1. Make sure the probe is in the GD position.
2. Using the 1/16-inch hex key, loosen the Probe Set Screw.
3. Be careful not to loosen the screw too much or it may fall out. Loosen it just enough for
the probe to slide easily out of the sleeve.
4. Remove the old probe from the sleeve.
5. Slide the new probe up into the sleeve.
6. Adjust the probe to the approximate desired height following the procedure described in
Exercise Sheet 2-7-3 on page 2-2-52.
7. Use the 1/16-inch hex key to tighten the Probe Set Screw.
8. Perform any necessary probe height adjustments following the procedures earlier in this
section.
9. Configure the Height Sensor (See Exercise Sheet 2-7-2 on page 2-2-50).
