Nordson Asymtek M-2000 - Symptoms and Causes of Pneumatic Failure

Trainee Guide TR-L2-M2000
Level 2 Maintenance Training – M2000 Dispensing Systems 4-2-10 P/N 73-0018-00 (Revision B)
Information Sheet 4-3-1
Symptoms and Causes of Pneumatic Failure
Symptom Possible Cause Recovery
Main Air Switch is Off. - Turn Main Air Switch On.
No Fluid Pressure
Air Pressure - Make sure that the Fluid
Pressure Regulator is set to the
proper air pressure.
Leaky Regulator
Damaged Regulator - Contact Asymtek Technical
Support.
- The regulator will need to be
replaced.
Main Air Switch Off - Make sure Main Air Switch is On.
Air Pressure - Make sure Valve Pressure
Regulator is set to the proper air
pressure.
Syringe disconnected - Connect the syringe receiver
head to the Valve Off (black
hose) port on the dispensing
head.
Interface PCA - Call Service Technician
- Replace Interface PCA. See
Exercise Sheet 5-5-1 on page
5-2-18.
Interconnect PCA - Call Service Technician
- Replace Interconnect PCA. See
Lesson 5-5, Module and PCA
Replacement, on page 5-2-17.
Pneumatic Solenoids - Call Service Technician
No Valve Pressure
Interconnecting Cables - Check cable connections
- Call Service Technician
.
.
.
