Information Sheet 4-4-1
Symptoms and Causes of Conveyor Failure
Symptom Possible Cause Recovery
Conveyor Controller Module
Fuse
Main PCA
- Replace fuse
- Call Service Technician
Cannot Adjust
Width/Belt Does Not
Move
Conveyor Motor - Call Service Technician
Conveyor Controller Module
- Check cable connections.
- Call Service Technician
Fails to Find Width
Home
Home PCA
- Call Service Technician
Conveyor Controller Module
- Check cable connections.
- Call Service Technician
Interface Module
- Check cable connections.
- Call Service Technician
Interconnect Module
- Check cable connections.
- Call Service Technician
Pneumatics Module
- Check cable connections.
- Call Service Technician
Stop Pins/Bar Clamps
Inoperative
Interconnect Cables
- Check cable connections.
- Call Service Technician
Conveyor Controller Module
- Check cable connections.
- Call Service Technician
Interface Module
- Check cable connections.
- Call Service Technician
Interconnect Module
- Check cable connections.
- Call Service Technician
Sensor
- Adjust board sensor sensitivity.
- Call Service Technician
Sensor Failure
Interconnect Cables
- Call Service Technician
No Functionality
Conveyor Controller Module
Fuse
- Call Service Technician
Replace Fuse
SMEMA Cables not Connected - Connect cables
Conveyor Controller Module
- Check cable connections.
- Call Service Technician
Interface Module
- Check cable connections.
- Call Service Technician
No
Upstream/Downstream
Interface
Upstream/Downstream System - Call Service Technician
