Trainee Guide TR-L2-M2000
Level 2 Maintenance Training - M2000 Dispensing Systems 2-2-86 P/N 73-0018-00 (Revision B)
Exercise Sheet 2-11-1
Removing and Replacing Heater Modules
1. Turn the Main Power Switch OFF (O).
2. Unplug all power cords.
3. Unplug the Heating Module Thermocouple Cable.
4. Disconnect the module airflow hose.
5. Unplug the Heating Module Power Cable.
6. Remove the module by gently lifting up on it.
7. Place the new module in the proper location.
8. Plug in the Heating Module Power Cable.
9. Connect the module airflow hose.
10. Plug in the Heating Module Power Cable.
11. Reconnect all power cords to the dispensing system.
12. Turn the Main Power Switch ON (I).
