Trainee Guide TR-L2-M2000
Level 2 Maintenance Training – M2000 Dispensing Systems 4-2-52 P/N 73-0018-00 (Revision B)
Exercise Sheet 4-13-1
Conveyor I/O Testing
1. Check that conveyor belt forward and backward movement is smooth and
controlled using the Position Controls.
2. Use the Jog Commands to open the Position Control dialog box for the conveyor.
 Press Home to send the conveyor home.
 Press Reinitialize to reset the conveyor.
3. Click Tools in the FmNT Main Window.
4. Click I/O Test in the Tools Window.
5. Click Conveyor.
6. Click the Inputs Tab.
7. Adjust the width to fit a sample board using the Position Controls.
8. Load the sample board into the Conveyor Port.
9. Locate the bit labeled CV-1_Sensor_Left in the I/O Test dialog box.
10. Move the board under or over the part sensor manually.
11. Check that the CV1_Sensor_Left bit in the I/O Test dialog box toggles ON and
OFF as the board passes under or over the sensor.
12. Repeat Steps 11-12 for each part sensor on your dispensing system.
13. Click OK in the I/O Test dialog box.
14. You may also check the Conveyor outputs by clicking on the Output tab and
clicking on the bit to the left of the desired output to toggle it on and off.
