Trainee Guide TR-L2-M2000
Level 2 Maintenance Training – M2000 Dispensing Systems 4-2-51 P/N 73-0018-00 (Revision B)
Information Sheet 4-13-2
Testing the I/O Functions of the Dispenser and Conveyor (Continued)
C. Dispenser I/O Test
1. The Dispenser I/O Test window lists all of the Inputs and Outputs associated with
the Dispenser.
2. This window can be accessed, and these functions performed from the I/O Test
button in the Tools Window.
3. You can test each I/O by clicking on the button to the left of the I/O name to turn it
ON (1) or OFF (0) and checking to make sure that the corresponding component
responds.
4. The PIO Bus tab allows you to perform Read and Write tests for valve function, light
level and air pressure.
5. This dialog box may also include a Control tab containing Position Controls for
moving the dispensing head.
