Trainee Guide TR-L2-M2000
Level 2 Maintenance Training - M2000 Dispensing Systems 2-2-57 P/N 73-0018-00 (Revision B)
Outline Sheet 2-8-1
Linear Encoders
A. Introduction
Linear encoders are mounted on each axis and keep track of the actual dispensing head
position. If the dispensing head starts and then stops, or loses its position, it may be
necessary to adjust the encoders.
B. Enabling Objective
2.8 Perform the procedure to adjust the Linear Encoders.
C. Topic Outline
1. Introduction
2. Overview
 Linear Encoders
 Linear Encoder Calibration
3. Summary and Review
