Page #168 background image
Trainee Guide TR-L2-M2000
Level 2 Maintenance Training - M2000 Dispensing Systems 2-2-104 P/N 73-0018-00 (Revision B)
Information Sheet 2-14-1
Tooling Flow Control Adjustment
A. Lift Tables/Clamp Bars
1. The lift tables or clamp bars raise to hold the part in place when it is being
dispensed upon.
2. For optimum operation, the lift tables and/or clamp bars should raise and lower at
the same time and at the same rate.
B. Stop Pins
1. Stop pins are pneumatic devices used to stop parts at each station.
2. The stop pins should raise and lower smoothly and quickly.
C. Tooling Flow Controls
1. The tooling flow controls regulate the amount of air pressure provided to the lift
tables and clamp bars.
2. Air pressure to stop pins is constant and does not need to be adjusted.
3. The amount of air pressure supplied to each device controls the speed of its up and
down movement.
4. It may be necessary to adjust the tooling flow controls to ensure that the lift tables
and/or clamp bars raise and lower at the same time and at the same rate.
5. The location of the tooling flow controls depends upon the device.
 The flow controls for clamp bars are located directly on the pneumatic cylinder
for that device.
 The flow controls for lift tables are located on the pneumatic hoses inside of the
dispensing area, near the rear of the system.
