Trainee Guide TR-L2-M2000
Level 2 Maintenance Training – M2000 Dispensing Systems 4-2-41 P/N 73-0018-00 (Revision B)
Outline Sheet 4-11-1
Removing and Replacing Fuses
A. Introduction
There are approximately fifteen fuses on most M-2000 Series Dispensing Systems,
depending upon your system heater configuration. Occasionally, you may need to replace
a fuse.
B. Enabling Objective
4.11 Locate fuses on the M-2000 Series Systems and perform the procedure to replace
them.
C. Topic Outline
1. Introduction
2. Overview
 Board Mounted Fuse
 Panel Mounted Fuse
3. Summary and Review
