Trainee Guide TR-L2-M2000
Level 2 Maintenance Training – M2000 Dispensing Systems 1-2-32 P/N 73-0018-00 (Revision B)
Information Sheet 1-7-1
Facility Requirements
A. Facility Requirements
1. To ensure optimal performance and safety, the M-2000 dispensing system must be
installed in a facility that meets or exceeds the following requirements.
Facility Requirements
System Footprint* 1118 X 1098 mm (44 X 43.2 in.)
Power Requirements 230 VAC, 50/60 Hz, 30 A
Air Pressure
551 kPA, 5.5 bar, 28 liter/hr, (80 PSI, 1 CFM, up
to 5 CFM for some configurations)
Shipping Weight** 732 kg (1614 lbs.)
* System requires an additional 796 mm (31 in.) in front and 717 mm (28 in.) in the rear to open the front and rear
access panels, respectively.
**
Includes the dispensing system and accessories crate. Actual weight may vary depending upon dispensing
system options.
2. All air hoses must be checked routinely and all facility power sources must be safely
grounded.
B. Facility Safety Precautions
1. Make sure that your facility meets or exceeds all facility requirements.
2. M-2000 installation should only be performed by a trained service technician.
3. If the dispensing system is located inside of a clean-room, make sure that all
documentation materials meet clean-room standards.
4. Make sure that all connections on the power cords and air supply hoses are solid
connections.
5. Make sure that the power cords do not cross a walkway or aisle.
6. Make sure that the air supply hose does not cross a walkway or aisle.
