Trainee Guide TR-L2-M2000
Level 2 Maintenance Training – M2000 Dispensing Systems 4-2-43 P/N 73-0018-00 (Revision B)
Exercise Sheet 4-11-1
Removing and Replacing Main Line Fuses
1. Turn the Main Circuit Breaker OFF (0).
2. Unplug all power cords.
3. Determine which fuse needs to be replaced.
4. Insert the small flat head screwdriver into the slot at the top or on the side of the fuse
box and gently pry it open.
 The main line fuse on the 201 Controller Modules is in a box that detaches from the
module. Inside of this fuse box, there are two fuses. Both of these fuses are active.
5. Remove the damaged fuse.
 You should be able to remove the main line fuses on the Conveyor Controller Module
with your fingers. Replace the damaged fuse with the proper replacement fuse.
6. Return the fuse box to its closed position.
7. Reconnect all power cords to the dispensing system.
8. Turn the Main Circuit Breaker ON (I).
