Trainee Guide TR-L2-M2000
Level 2 Maintenance Training - M2000 Dispensing Systems 2-2-48 P/N 73-0018-00 (Revision B)
Exercise Sheet 2-7-1
Setting Up the HS-Series Height Sensor
1. Check the locating of the Micrometer Locking Screw (See Diagram Sheet 2-7-1 on
page 2-2-49).
2. Loosen the Micrometer Locking Screw.
3. Adjust the Micrometer Adjustment until the Micrometer Locking Screw is centered in
the slot.
4. After centering the screw, it is recommended that you adjust the Micrometer
Adjustment to “0” as a starting point for any future probe adjustments.
5. Tighten the Micrometer Locking Screw.
6. Perform Probe Adjustments, if necessary (See Exercise Sheet 2-7-3 on page
2-2-52).
7. Configure the Height Sensor (See Exercise Sheet 2-7-2 on page 2-2-50).
To Next Page
