Trainee Guide TR-L2-M2000
Level 2 Maintenance Training - M2000 Dispensing Systems 2-2-94 P/N 73-0018-00 (Revision B)
Exercise Sheet 2-12-1
Conveyor Configuration
1. Select Setup Conveyors from the Configuration menu.
2. The Setup Conveyors dialog box opens.
3. Click on the arrow next to the Type box and select the type of conveyor installed
on your system.
 Most M-2000 Series Dispensing Systems use Automove to communicate
with the conveyor.
 If you are using a non-Asymtek conveyor, select Custom.
 MPC555 is used on the X-1000 Series Dispensing System.
 If your dispensing system is not equipped with a conveyor, select (none).
4. To select the exact conveyor style and conveyor atom to use on your dispensing
system, click on Configure in the Setup Conveyors dialog box.
5. The Setup Configuration–Conveyor dialog box opens.
6. Click on the arrow under Style to view the entire list of conveyor types.
 A brief description of each conveyor type appears below the Style box.
 The selected conveyor Style determines the name of the Conveyor Files
used during operation.
 Refer to the Online Help for explanations of each feature in this dialog box.
7. Click on OK.
8. The Setup Configuration–Conveyor dialog box closes and you return to the Setup
Conveyors dialog box.
9. Click on OK.
